For refrigerated display cases and vending machines Permanently lubricated bearings Individually boxed Impedance protected Suitable for all angle operation 24 Inch cord with molded strain relief Cast iron housing Includes vibration dampener hub washer, speed nut, and (4) mounting screws. Application: Refrigeration evaporator or condenser fan FLA at 115V (A): 0.60 Frequency (Hz): 50/60 High speed (RPM): 1550 HP: 9W Input voltage (V): 115 Motor body diameter (inch): 3-19/32 Motor body length (inch): 3-13/16 Motor type: RESCUE shaded pole Mounting: 11 Tapped holes for 8-36 mounting screws Overall motor length (inch): 4-19/64 Overall shaft length (inch): 1/2 Rotation direction (OSE): CW Shaft diameter (inch): 1/4 Shaft style: 20THD. It is important to disconnect from the power supply before servicing.. Supplying Demand replacement parts are compatible with Major Brands, but you should always verify fitment with your specific application.. SD products come in Supplying Demand packaging..
