Description:

XINCOL Switched Mode Power Supplies(SMPS) are being designed with unique state of the art current mode PWM technology, widely used in LED lighting, Home Appliance, Instrumentation, Office Automation, CCTV, Process and Engineering Industries etc. Technical Details: Model: XC-240-12 Safety Appliance: FCC/CE/RoHS Protection: Shortage circuit, Overload, Over Voltage, Over Temperature Protection Input: AC110V/220V Output: DC12V 20A Output Power: 120W Number of Output: +V x 3, -V x 3 Frequency: 50/60Hz Working temperature:040 Storage Temperature: -2060 Ambient Humidity: 095% Non-Condensation Shell Material: Metal case / Aluminum base Silver Tone Size:7. 87 inchx4. 33 inchx1. 97 inch/200mmx110mmx50mm(L*W*H) Net Weight:758g Connection L, N: AC power input COM: DC power output V: DC power output + +V / ADJ: Adjust the output voltage (15%) Package Contents: 1 x XINCOL LED Switching Power Supply 20A 240W Note: 1. If you live in the US, the voltage switch of the power supply should be set to 110/115. Setting the power supply voltage switch to the incorrect input voltage could damage the power supply 2. The unit can work long hours at this current and good cooling environment. The actual output current depends on circuit loads 3. Dust the switcher out every 2 or 3 months if necessary 5. Even with EMI/RFI filter built inside, still not suitable for a hamradio operator connecting with radio or wireless communication equipments. 6. Do not power the unit before wire connection and voltage adjustment 7. IN-DOOR USE ONLY! This Unit "DOES NOT" comes with installation instruction, wiring cable, on/off switch, or screws. Professional installation of qualified electrician is highly recommended. Features: Switch power supply, convert AC 110V/220V to DC 12V 20A 240W Dual input voltage: AC 110V/220V. Wide voltage input adjusted automatically to SMPS Model (12V 1A-5A, 12W-60W). As for Model (12V 10A-60A 120W-600W), there is a voltage selector switch located on the side of the switcher is used to set the input voltage to the power supply to either 110V/115V or 220V/230V. Smart device surge protection for Shortage Protection, Overload Protection, Over VoltageOver Temperature Protection. High efficiency, High Reliability, Low Temperature Rise Built-in EMI filter, low output ripple, noise, Rugged heavy duty enclosure, 100% Full load burn-in Tested. Parallel/Redundancy Operation is possible. Widely being used in Industrial automation, LED display, electronic equipments, communications etc. Item Dimensions: 7. 87" L x 4. 33" W x 1. 97" H.
